Impedance 50Ω RF Antenna Connector , SMA Panel Mount Connector For Aerospace

Impedance 50Ω RF Antenna Connector , SMA Panel Mount Connector For Aerospace

sma bulkhead connector

sma coax connector

Place of Origin:

China

Certification:

CE ROHS

Contact Us
Request A Quote
Product Details
Model:
SMA-KFB2A
Gender:
Female
Frequency:
DC~18GHz
Durability:
500 Cycles
Plating:
Nickel Plated
Impedance:
50Ω
Application:
Aerospace
Product Name:
SMA RF Coaxial Conector
Highlight:

sma bulkhead connector

,

sma coax connector

Payment & Shipping Terms
Minimum Order Quantity
Negotiable
Price
Negotiable
Packaging Details
Standard Export Carton
Delivery Time
Within 3 weeks
Payment Terms
T/T, Western Union, L/C
Supply Ability
1,000,000 Pieces Per Month
Product Description

Gold Plated SMA Male Plug Straight Solder RF Coaxial Connector Attachment 50Ohm

SMA series is a kinds of mini, high-frequency RF coaxial connector, it's developed and produced according to MIL-C-39012. With characteristics of small volume,good bandwidth,superior electrical characteristics. SMA is the most widely used rf coaxial connectors in different fields of microwave communication and microwave measuring device.The high performance connector developed by our company can reach to 20GHz.



Impedance 50Ω RF Antenna Connector , SMA Panel Mount Connector For Aerospace 0



Specification:



Electrical Characteristics
Impedance 50Ω
Frequency Range Connect with solf cable DC~12.4GHz
Connect with semi-rigid cable DC~18GHz
Rated Voltage 335VRMS
Dielectrics Voltage-resistance 1000VRMS
Insulation Resistance ≥5000MΩ
Center Resistance Center Conductor ≤3.0mΩ
Outer Conductor ≤2.0mΩ
VSWR ≤1.3
Material & Mechanical Characteristics
Center Conductor Male Brass Gold plated
Female Sn-P Bronze Gold plated
Elastic Contact Beryllium bronze Nickel plated
Shell and other Metal Parts Brass Nickel plated
Stainless  Passivation
Crimping Sleeve Brass Nickel plated
Insulators PTFE
Sealing Ring Silicone Rubber
Durability 500 cycles
Tightening torque of connection 0.79-1.13N .m





Features:



1. SMA RF connector is high quality and quick combinations by simply screwing two connectors together, with no soldering or crimping required
2. SMA electrical connectors are widely used for microwave, antennas and testing instrumentation etc
3. SMA RF connectors are available in quick connect , push-on or standard interface , straight, 90 degrees versions,as well as bulkhead ,or 4 hole panel configurations
4. SMA RF connector are threaded-coupling RF coaxial connectors with miniature size, vibration-proof and wide frequency range up to 18 GHz (Our SMA RF connectors can be 20 GHz)






Application:


* Aerospace
* Broadband
* Instrumentation
* Phased array antennas
* Telecommunications

* Board-to-board interconnect



More Detail:

Impedance 50Ω RF Antenna Connector , SMA Panel Mount Connector For Aerospace 1Impedance 50Ω RF Antenna Connector , SMA Panel Mount Connector For Aerospace 2





Product Cataloge:

RF Adapter
SMA/SSMA RF Connector
SMP/SSMP RF Connector
TNC RF Connector
N Type RF Connector
MCX/MMCX RF Connector
BNC RF ConnectorMillimeter Wave Connectors(2.4mm, 2.92mm)
RF Cable Assemblies
Waveguide To Coaxial Adapter
Glass-to-metal Hermetic Seals
J30J Series Connector
Microwave Rotary Joints



NOTE:
We have over 10,000 types of SMA Connector, if the connector you are using is not found, please contact us with your details.
